Wi-Fi Module
M2-JODY-W377-00C is a Wi-Fi expansion card for engineers who need to add wireless networking to a host system with a spare PCIe-based slot. It covers IEEE 802.11a/b/g/n/ac/ax on both 2.4 GHz and 5 GHz, with channel bandwidths of 20, 40 and 80 MHz, so it can be configured for a range of network layouts.The card has an integrated power amplifier with transmit power up to +19 dBm and receive sensitivity as low as -97 dBm. Encryption options are Open, WPA, WPA2 and WPA3. In access point mode it supports up to 64 clients. It is listed for RED, UKCA, FCC, RoHS and WEEE compliance.Electrical and mechanical details include a +3.135 VDC to +3.465 VDC input range, a consumption of 6.6 W (2 A at 3.3 VDC), dimensions of 22.0 x 30.0 x 4.2 mm (W x L x H) and an operating temperature range of -40 ~ +85 °C. Ordering code: M2-JODY-W377-00C CR.
