XW514 8-Port RS-485 Expansion Board for uPAC and WP Controllers
8-port non-isolated RS-485 expansion board for uPAC-50xx and WP-51xx controllers, with 128-byte FIFO buffers and speeds up to 115,200 bps.
- Eight RS-485 serial ports on a single expansion board
- Communication speeds up to 115,200 bps
- 128-byte FIFO buffer on each port
- Parity options: None, Even, Odd, Mark, Space
- Data bits 5, 6, 7 or 8; stop bits 1, 1.5 or 2
- Non-isolated design, 0.6 W power consumption
261,00 € per piece
| 1–9 pcs | 261,00 € | |
|---|---|---|
| 10–30 pcs | 253,00 € | −3 % |
| 31+ pcs | 248,00 € | −5 % |
Info sui prodotti "XW514 8-Port RS-485 Expansion Board for uPAC and WP Controllers"
XW514 CR adds eight RS-485 serial ports to uPAC-50xx and WP-51xx series controllers. It suits projects where a controller needs to talk to several serial devices at once without moving to a separate communication gateway.
Each port has a 128-byte FIFO buffer and can run at up to 115,200 bps. Parity, data bit and stop bit settings are configurable across the ranges listed below, so the board can match a wide variety of serial devices. The board is non-isolated and is specified for an operating range of -25 to +75 °C.
Typical connections include bar code readers, intelligent sensors, instrumentation equipment, computers and other devices fitted with an RS-485 port. The board draws 0.6 W and measures 66 x 82 x 13 mm (W x L x H).
Applications
- Serial device connections for uPAC-50xx and WP-51xx controller systems
- Bar code readers and intelligent sensors
- Instrumentation equipment and computer-based serial links
| Product type: | Expansion board |
|---|---|
| Interface: | RS-485 |
| Ports: | 8 |
| Isolation: | Non-isolated |
| Operating temperature: | -25 ~ +75 °C |
Specifications
| COM Ports | |
|---|---|
| Ports | 8 x RS-485 |
| Baud Rate | 115200 bps Max. |
| Parity | None, Even, Odd, Mark, Space |
| Data Bit | 5, 6, 7, 8 |
| Stop Bit | 1, 1.5, 2 |
| FIFO Size | 128 bytes |
| Power | |
| Consumption | 0.6 W |
| Mechanical | |
| Dimensions (mm) | 66 mm x 82 mm x 13 mm (W x L x H) |
| Environment | |
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -30 °C ~ +75 °C |
| Humidity | 10 ~ 95% RH, Non-condensing |
Specifications as published by the manufacturer. Subject to change.
