LP-5231 Linux-Based PAC with Cortex-A8 1 GHz CPU and XV-Board Expansion
Linux-based PAC with a 1 GHz Cortex-A8 CPU, 512 MB RAM, a 10/100/1000 Ethernet port, four serial ports and an XV-Board I/O expansion bus for DIN-rail control.
- 1 GHz Cortex-A8 CPU running Linux kernel 3.2.14 with real-time capability
- 512 MB DDR3 SDRAM and 512 MB flash, with microSD storage
- 10/100/1000 Mbit/s Ethernet port plus four serial ports (RS-232/485)
- One RS-485 port isolated at 2500 VDC
- I/O Expansion Bus (XV-Board) for adding I/O modules
- 64-bit hardware serial number for software copy protection
This item is quoted per order. Send us your quantity and we reply with price and delivery time.
Request a quote
Já não está disponível
Informações de produto "LP-5231 Linux-Based PAC with Cortex-A8 1 GHz CPU and XV-Board Expansion"
LP-5231 CR is a LinPAC programmable automation controller built around a 1 GHz Cortex-A8 processor and Linux kernel 3.2.14. It suits engineers who need a Linux platform with real-time capability for time-critical control and data handling, supported by an SDK with a GCC-based toolchain and LinPAC libraries.
The controller provides 512 MB DDR3 SDRAM, 512 MB flash and a microSD socket (4 GB card supplied, up to 32 GB microSDHC supported) for programs, images and data. A 64 KB FRAM provides non-volatile memory, and a real-time clock and dual watchdog timer support robust operation.
Connectivity includes a 10/100/1000 Base-TX Ethernet port, four serial ports (RS-232 and RS-485, one RS-485 port isolated at 2500 VDC), a USB 2.0 host port and VGA output up to 1280 x 1024. The XV-Board expansion bus adds I/O, and the unit mounts on DIN-rail with a supply input of +12 VDC to +48 VDC.
Applications
- Distributed control with Linux-based application logic
- Multi-serial device communication
- Time-critical and high-performance automation tasks
- Remote access and management via web, SFTP and SSH services
| Product type: | PAC |
|---|---|
| Interface: | Ethernet, RS-232/485, USB 2.0 host, VGA, XV-Board |
| Ports: | 6 |
| Isolation: | 2500 VDC (one RS-485 port) |
| Power input: | +12 VDC ~ +48 VDC |
| Operating temperature: | -25 ~ +75 °C |
| Mounting: | DIN-rail |
| Housing: | Plastic |
Specifications
| Software | |
|---|---|
| OS | Linux Kernel 3.2.14 |
| Service | SFTP server, Web server, SSH |
| SDK | LinPAC SDK (GCC based toolchain and LinPAC Libraries) |
| Main Unit | |
| CPU | Cortex-A8, 1 GHz |
| 64-bit Hardware Serial Number | Yes, for Software Copy Protection |
| System Memory | 512 MB DDR3 SDRAM |
| Storage | • Flash 512 MB • microSD socket with a 4 GB microSD card (support up to 32 GB microSDHC card) |
| Non-Volatile Memory | FRAM 64 KB |
| Real Time Clock | Yes (Provide seconds, minutes, hours, day of week, month, year) |
| Watchdog Timer | Yes, Dual Watchdog Timer |
| Display | |
| Signal | VGA (Analog RGB) |
| Resolution | Up to 1280 x 1024 |
| LED Indicators | |
| Status | 1 x Power 1 x Run 2 x Programmable |
| I/O Expansion | |
| I/O Type | XV-board |
| HMI | |
| Rotary Switch | Yes (0 ~ 9) |
| Ethernet | |
| Ports | 1 x RJ-45, 10/100/1000 Base-TX |
| COM Ports | |
| Ports | 1 x RS-232 (Console, Non-isolated) 1 x RS-232, Non-isolated 1 x RS-485, Non-isolated 1 x RS-485 (2500 VDC, Isolated) |
| USB | |
| Ports | 1 |
| Specification | USB 2.0 (Host) |
| Power | |
| Input Range | +12 VDC ~ +48 VDC |
| Consumption | 4.8 W |
| Mechanical | |
| Casing | Plastic |
| Dimensions (mm) | 91 x 132 x 52 (W x L x H) |
| Installation | DIN-Rail Mounting |
| Environment | |
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -40 ~ +80 °C |
| Humidity | 10 ~ 95% RH, Non-condensing |
Specifications as published by the manufacturer. Subject to change.
